Introduction
PIR is a passive infrared detector or physical sensor. When the PIR is triggered, PIR will send message to the App. It could also trigger other devices like light, home application, siren and so on. The PIR is battery powered, is small and can be installed easily.
Parameters
1. Model: SH-PR01W
2. Battery: CR123A x 1
3. Battery Life: 1 years (25 times/day) 2years(10 times/day)
4. Standby current: 20uA
5. Detection range: 7 meters
6. Sensitive angle: 110°
7. Wireless Type: 2.4GHz
8. WiFi distance: 45m
9. Product size(L*W*H): 45 x 45 x 48mm
Features
• When alarm triggered, LED light flashes in the detection area.
• Easily install with screws or sticker .
• No hub requirement
